MAX RB823T TwinTier Rebar Tying Tool up to #14 x #14 with 19ga wire
Details
MAX RB823T TwinTier® Rebar Tying Tool up to #14 x #14 with 19ga wire
The TWINTIER® RB823T is the fastest solution for tying #7 x #7 to #14 x #14 (Or #18 x #8) rebar combinations, making it the largest capacity rebar tying tool on the market. TWINTIER® technology allows the RB823T to tie Approx. 4,100 ties per charge, while delivering just the right amount of wire for greater productivity and cost savings. Compared to hand tying this tool can reduce the risk of musculoskeletal injuries. See chart below for all applicable combinations.
Applications
- Footing
- Caisson, Drill Shaft, Column
- Cell Phone Tower
- Water Treatment
- Binding Rebars/ Cables
FEATURES
- LARGEST JAW CAPACITY EVER - The largest jaw size of any battery powered rebar tying tool on the market. This tool makes ties on two pieces of rebar (Up to #18x#8 or #14x#14) at the same time.
- FAST TYING - The RB823T tying speed is approximately 1/2 second for fast tying.
- LOAD ASSIST MECHANISM - New wire loading system automates wire loading for tool.
- EASY PULL TRIGGER - Reduced trigger effort is required, improving operational ergonomics.
SPECIFICATIONS
- WEIGHT: 6.0 lbs
- DIMENSIONS: 12-3/8"(H) x 4-7/8"(W) x 15-1/8"(L)
- MINIMUM TIES PER COIL: 85
- MAXIMUM TIES PER COIL: 165
- APPLICABLE WIRE PRODUCT/GA: TW1061-T Series / 19Ga.
- APPLICABLE REBAR SIZE: #7 x #7 - #14 x #14 (Or #18 x #8)* *Varies by rebar manufacturer
- TIES PER CHARGE: 4100
- TIE SPEED: less than 1/2 sec
- BATTERY CHARGE TIME: Approx. 80 minutes full charge (approx. 60 minutes 80%)
- BATTERY: JPL91450A
- CHARGER: JC925A
