#10 x 1" SQUARE DRIVE PANCAKE HEAD 410SS STRONG SHIELD SCREWS 4,000ct | 4PC8
Details
#10-12 x 1" Phillips Pancake Head Screws – 410 Stainless Steel with Strong-Shield Coating
These fasteners combine the strength of 410-grade stainless steel with the advanced corrosion resistance of Strong-Shield Coating. Designed for attaching panel clips to metal studs and wood applications.
Features:
- 410 Grade Stainless Steel with Strong-Shield Coating
- Attaches panel clips to metal studs
- Type 'A' thread for wood applications
- High degree of corrosion resistance
- Rust and acid rain protection
- ACQ treated lumber compatible
Details:
- Head Type: Pancake
- Head Diameter: 7/16"
- Drive: #2 Square
- Thread Diameter: #10
- Threads Per Inch: 12
- Length: 1"
- Point: #3 Self-Drilling
- Drill Capacity: .035 - .176
- Drill Speed: 2500 RPM
- Quantity: 4,000 pcs
- Weight: 30 pounds
Specifications:
- Meets F.I.P.-1000.7 for torsional strength and drill speed
- Meets SAE J78 for performance and dimensional specifications
- 410 Grade Stainless Steel
- Strong-Shield Coating
Enhanced Protection: 410 Stainless Steel can be hardened through heat treatment, allowing it to drill through metal. While it does not offer the same level of corrosion resistance as Type 316 or 305 stainless steel, the Strong-Shield Coating provides superior protection.
Four Times the Protection! These Strong-Shield coated fasteners feature a four-layer protective barrier that prevents corrosion. This includes a metallic zinc layer, a passivation layer, a functional nano-coating sealer, and a high-grade anticorrosion chemical conversion film. Rated at 1,000 hours of salt spray resistance, Strong-Shield Coating protects against rust and acid rain and is compatible with ACQ-treated lumber.
