4-1/2" OMG HeadLok Panel Fastener Gimlet Point 250ct | FMHLGM412-250

(0)No Reviews yet
$185.95
SKU: FMHLGM412-250
PACKAGING QTY: 250 count

Details

4-1/2" HeadLok Panel Fastener OMG FMHLGM412-250 for Wood


The OMG HeadLok is a specialized, flat head fastener engineered for a wide range of panel applications including Structural Insulated Panels, Prefabricated Wall Panels, and Nailboard, and can be used in wood, structural concrete,* corrugated and structural steel substrates.

Factory Mutual and Miami-Dade County Approved.
Physical Data

  • Fastener Length: 4-1/2" (115-mm)
  • Thead Length: 2" (51-mm)
  • Shank Diameter: .190-in. (4.82-mm)
  • Head Diameter: .625-in. (15.87-mm)
  • Head Style: 8 Lobe SpiderDrive
  • Point Type: Gimlet
  • Coating: OMG CR-10 corrosion resistant coating exhibits less than 15% red rust after 30 Kesternich cycles. CR-10 coating exceeds F.M. Approval Standard 4470.
  • Weight 12 pounds


Features & Benefits

  • Aggressive thread for holding power and withdrawal strength.
  • Chamfer under head for increased strength.
  • Extra large wafer head dramatically increases pull-through resistance and eliminates the need for additional washers.
  • ACQ tested and approved.
  • Install with SpiderDrive® bit system. Eliminates cam-out. Free drive bits in every bucket.
  • FM and Miami-Dade County Approved.


Application

  • Install the OMG HeadLok using a high torque, low RPM screw gun. Bring underside of the washer head flat to the surface. Do not overdrive. For steel substrates, proper point style must be determined depending on the steel gauge thickness.
  • For structural concrete: use the OMG HeadLok with spade points only. Predrilling is required. Pull tests should always be performed to determine proper hole/drill bit size. Pilot holes should be at least a 1/2-in. (13-mm) deeper than fastener embedment.
